Specifications:
- Product Collection: 13th Generation Intel® Core™ i7 Processors
- Code Name: Products formerly Raptor Lake
- Vertical Segment: Desktop
- Processor Number: i7-13700KF
- Launch Date: Q4'22
- Lithography: Intel 7
- Total Cores: 16
- # of Performance-cores:8
- # of Efficient-cores:8
- Total Threads: 24
- Max Turbo Frequency: 5.40 GHz
- Intel® Turbo Boost Max Technology 3.0 Frequency: 5.40 GHz
- Performance-core Max Turbo Frequency: 5.30 GHz
- Efficient-core Max Turbo Frequency: 4.20 GHz
- Performance-core Base Frequency: 3.40 GHz
- Efficient-core Base Frequency: 2.50 GHz
- Cache: 30 MB Intel® Smart Cache
- Total L2 Cache: 24 MB
- Processor Base Power: 125 W
- Maximum Turbo Power: 253 W
- Max Memory Size (dependent on memory type): 128 GB
- Memory Types: Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s
- Max # of Memory Channels: 2
- Max Memory Bandwidth: 89.6 GB/s
- Direct Media Interface (DMI) Revision: 4.0
- Max # of DMI Lanes: 8
- Scalability: 1S Only
- PCI Express Revision: 5.0 and 4.0
- PCI Express Configurations: Up to 1x16 4, 2x8 4
- Max # of PCI Express Lanes: 20
- Sockets Supported: FCLGA1700
- Max CPU Configuration: 1
- TJUNCTION: 100°C
